| Specifications of ARE-312 Planetary Paste Mixer |
|
|
| Product name |
|
Planetary Centrifugal Mixer (THINKY MIXER) |
|
| Model |
|
ARE-312 |
|
| System |
|
Planetary propeller-less mixing |
|
| Operation Time Setting |
|
Timer setting range : 0 s to 30 min in 1 s increments |
|
| Revolution Speed : Mixing mode |
|
0 rpm or 200 to 2200 rpm (adjustable in 10 rpm increments) |
|
| Revolution Speed : Defoaming mode |
|
0 rpm or 400 to 2400 rpm (adjustable in 10rpm increments) |
|
| Rotation Speed : Mixing mode |
|
Maximum of 880 rpm (1/2.5 relative to revolution speed) |
|
| Rotation Speed : Defoaming mode |
|
Defoaming mode / Maximum of 65 rpm (1/36.7 relative to revolution speed) |
|
| External Communication Function |
|
RS232C serial port ( D sub 9 pin ) |
|
| Programming Function |
|
20 memories with 10 steps |
|
| Revolution speed (Mixing mode) |
|
20 memories with 10 steps |
|
| Standard Container |
|
Inner volume:300 ml and 150 ml , Material: HDPE |
|
| Maximum Capacity |
|
310 g |
|
| Power Supply : Voltage |
|
Single-phase, AC100～230V±10％、50/60Hz |
|
| Power Supply : Power Consumption |
|
Approx. 50 VA (standby), Max 900 VA (operation) |
|
| Operating Environment |
|
10 to 35 ℃, 35 to 85 % RH (without condensation) |
|
| Safety Mechanism |
|
Revolution Sensor, Vibration Sensor, impact Sensor, Door Sensor |
|
| Unit Dimensions |
|
H390 × W300 × D340 (mm) |
|
| Unit Weight |
|
Approx. 21 kg |
|
